Telescopic Boom Lifts

Liugong 01

LiuGong LT20J

1

Specifications

Max Working Height

Max Platform Extension Length

Platform Load (Unrestricted)

Machine Gradeability (4WD)

Drive Speed (Stowed / Raised)

Turret Rotation

Platform Rotation

Platform Dimensions

Turning Radius (Inside / Outside)

Driving Steering Type

Power

Machine Weight

22,000

17,200

454 Kg

45%

4.8 / 1.1 Km/h

360° (Con)

135°

2,400 x 910

2,400 / 5,500

4WD

Yuchai 36.8kW

12,300 Kg

2
3
4
5

Standard Features

LiuGong’s LT20J Self-Propelled Telescopic Boom lift offers a range of features and benefits. With its self-propelled capability, telescopic boom design, high working height, and compact size, it provides operators with increased mobility, reach, and flexibility. Safety features, durable construction, user-friendly controls, and easy maintenance further enhance its usability. Whether for construction, maintenance, or other applications, the LT20J is a reliable and versatile solution.

The LT20J is a self-propelled telescopic boom lift, meaning it can be easily maneuvered without the need for additional external equipment. This feature offers increased mobility and flexibility on various job sites. The LT20J features a telescopic boom, allowing for extended reach and enhanced working height capabilities. Operators can access elevated areas efficiently, making it suitable for tasks such as construction, maintenance, or repair work.

This boom lift is equipped with intuitive and user-friendly controls, enhancing ease of operation. Operators can quickly and efficiently control the lift’s movements, allowing for precise positioning and reaching desired work areas. Safety is prioritized in the LT20J, with features such as emergency stop buttons, safety harness attachment points, non-slip platforms, and load sensors. These safety measures ensure the well-being of operators and workers during operation.

This boom lift provides a high working height, allowing operators to reach considerable heights with ease. This is particularly useful for tasks that require working on tall structures or accessing hard-to-reach areas. Despite its impressive capabilities, the LT20J boasts a compact design, making it suitable for work in confined or tight spaces. Its compact size allows for easy maneuverability and positioning, even in congested job sites.

Equipped with sturdy tires and a reliable drivetrain, the LT20J has all-terrain capability. It can navigate various types of surfaces, including rough or uneven terrains, ensuring operators can access work areas with ease. The LT20J is versatile and suitable for a wide range of applications. From construction and maintenance to utility work and event setup, this boom lift can be utilized in different industries and job sites.

LiuGong LT20JE

1

Specifications

Max Working Height

Max Platform Extension Length

Platform Load (Unrestricted)

Machine Gradeability (4WD)

Drive Speed (Stowed / Raised)

Turret Rotation

Platform Rotation

Platform Dimensions

Turning Radius (Inside / Outside)

Driving Steering Type

Power (Battery)

Machine Weight

21,500

13,400

320 Kg

45%

5 / 1 Km/h

360° (Con)

90°

1,830 x 760 x 1,100

2,400 / 5,500

4WD x 2WS

48V / 460Ah

9,500 Kg

2
3
4

Standard Features

Elevating efficiency and safety in vertical access. LiuGong’s Electric Telescopic Boom Lifts operate entirely on electric power, reducing dependence on traditional fuel sources. By utilizing electricity, it eliminates emissions and promotes environmental sustainability, making it an eco-friendly choice for your work site. The lifts boasts a telescopic boom with impressive vertical and horizontal reach capabilities. Equipped with state-of-the-art control systems for precise and intuitive operation. The advanced controls allow for smooth and accurate maneuvering, ensuring exceptional safety and efficiency.

The LT20JE is powered by electricity, offering eco-friendly operation with zero emissions. This makes it an ideal choice for indoor use or environments where low noise and clean operation are required. The LT20JE features a telescopic boom that extends to provide increased working height and reach. This allows operators to access elevated areas efficiently and perform tasks at various heights. With its telescopic boom design, the LT20JE offers a high working height, enabling operators to reach tall structures or inaccessible areas with ease. This makes it suitable for a wide range of applications, including maintenance, construction, or installation work.

As an electric-powered boom lift, the LT20JE operates quietly, minimizing noise pollution. This is beneficial for work in noise-sensitive environments or when conducting tasks where quiet operation is necessary, such as in residential areas or during events. The LT20JE is equipped with user-friendly controls, allowing operators to easily and precisely maneuver the boom lift. This enhances productivity and ensures efficient operation. Safety is a priority in the LT20JE, featuring safety devices such as emergency stop buttons, integrated harness attachment points, non-slip platforms, and load sensors. These safety features ensure the well-being of operators and workers during operation.

The LT20JE has a zero tail swing design, meaning the rear of the machine doesn’t extend beyond the footprint of the tracks. This makes it highly maneuverable in tight spaces and eliminates the risk of accidental collisions. The LT20JE has a compact design, allowing for easy maneuverability in confined spaces. This makes it suitable for indoor work or jobsites with limited space. Equipped with sturdy tires and a robust drivetrain, the LT20JE has the capability to operate on various terrains. This allows operators to navigate rough or uneven surfaces, providing versatility for different job site conditions.

LiuGong LT26JE

1

Specifications

Max Working Height

Max Platform Extension Length

Platform Load (Unrestricted)

Machine Gradeability (4WD)

Drive Speed (Stowed / Raised)

Turret Rotation

Platform Rotation

Platform Dimensions

Turning Radius (Inside / Outside)

Driving Steering Type

Power (Battery)

Machine Weight

28,000

19,280

320 Kg

45%

5 / 1 Km/h

360° (Con)

90°

 2,440 x 910 x 1,100

3,500 / 6,800

4WD x 2WS

80V / 460Ah

15,000 Kg

2

Standard Features

LiuGong’s LT26JE Telescopic Boom Lift offers a range of features and benefits. As an electric-powered lift, it provides a clean and quiet operation, contributing to a sustainable and comfortable work environment. Equipped with a telescopic boom, it allows for extended reach and high working heights. The lift’s compact design enables it to navigate in tight spaces, while its powerful performance ensures efficient task completion. With multiple control options, safety features, and easy maintenance, the LT26JE is a reliable and versatile choice for a variety of applications.

The LT26JE Telescopic Boom Lift is powered by electricity, offering a green and sustainable solution. With zero emissions and reduced noise levels, it provides a cleaner and quieter working environment compared to diesel-powered lifts. This boom lift is designed with a telescopic boom, allowing for extended reach and height capabilities. The telescopic boom can be smoothly extended or retracted, providing operators with greater flexibility to access elevated work areas efficiently.

The boom lift is equipped with multiple control options, such as a platform control panel and a ground-level control station. This provides flexibility and convenience, allowing operators to control the lift from the most suitable location for the task at hand. The LT26JE is equipped with essential safety features to ensure the well-being of operators and workers. These may include emergency stop buttons, safety harness attachment points, non-slip platforms, and load sensors. Safe operation is prioritized in its design.

The LT26JE offers a high working height, enabling operators to reach towering heights with ease. This is particularly advantageous for tasks such as construction, maintenance, or repair work on buildings, utilities, or infrastructure. The telescopic boom on the LT26JE provides a considerable horizontal outreach. This allows operators to access remote or difficult-to-reach areas without needing to reposition the entire machine, enhancing productivity and efficiency.

LiuGong LT26JG4

1

Specifications

Max Working Height

Max Platform Extension Length

Platform Load (Unrestricted)

Machine Gradeability (4WD)

Drive Speed (Stowed / Raised)

Turret Rotation

Platform Rotation

Platform Dimensions

Turning Radius (Inside / Outside)

Driving Steering Type

Power (Engine)

Machine Weight

28,190

23,430

300/454 Kg

45%

5 / 0.6 Km/h

360° (Con)

90°

 2,440 x 910 x 1,100

3,600 / 6,700

4WD x 2WS

Yuchai 55kW

18,680 Kg

2
3
4

Standard Features

Introducing the LiuGong LT26JG4 Telescopic Boom Lift, your trusted partner for reaching new heights safely and efficiently. With an array of advanced features and benefits, this cutting-edge machine sets the standard for excellence in aerial access solutions. Explore the exceptional qualities that make the LT26JG4 the ultimate choice for your elevated work needs.

Double Redundancy Design: The LT26JG4 prioritizes safety with its double redundancy design of limit switches and long-angle sensors. Each working range is under precise control, ensuring the utmost safety.
Platform Load Monitoring: Continuous monitoring of platform load with high-precision weighing sensors guarantees the safety of your crew and equipment. Virtual Wall Protection: Customize your safety measures with configurable virtual wall protection, effectively safeguarding the operator’s well-being.

Impressive Load Capacity: With an unrestricted load of 300kg and a 454kg restricted area load throughout the entire working range, the LT26JG4 handles even your most demanding tasks with ease. Hydraulic Drive: A closed hydraulic drive system, combined with a variable main pump and electric proportional control, ensures stable and efficient operation. Automatic Balance Swing Bridge: Designed for complex working conditions, the automatic balance swing bridge provides stability and precision. Four-Wheel Drive: Enjoy faster response times with the fully hydraulic four-wheel drive system, providing superior maneuverability. Multi-Functional Joystick: The multi-functional combined Hall full-scale effect joystick streamlines operation, enhancing efficiency and operator comfort.

Impressive Working Range: The LT26JG4 offers a maximum working height of 28 meters and a maximum working outreach of 23.4 meters, providing a wide working range for various tasks.
Versatile Jib: The jib can rotate vertically at 135°, offering a working range from 60° downward to 75° upward.
Space-Saving Design: The four-bar linkage design results in a compact structure, making it easier to navigate tight spaces.

Real-Time Monitoring: Stay ahead of maintenance with real-time monitoring and transmission of vehicle information, historical fault record queries, and helpful maintenance tips. Working Condition Records: Keep comprehensive records of your equipment’s working conditions for better maintenance planning. Self-Lubricating Bearing: Maintenance is hassle-free with self-lubricating bearings and a screw-out engine tray.

The LT26JG4 comes equipped with a range of standard features, including platform working lights, a flashing amber beacon, anti-extrusion and over-tilt protective systems, a load sensing system, platform self-locking door, two-wheel steering, an auto brake system, all motion alarm, emergency descent and stop systems, automatic leveling, electro-hydraulic proportional control, a spacious three-entry large working platform, hydraulic oil dispersion, double work area, and a remote fault diagnosis system.

LiuGong LT28JG4

1

Specifications

Max Working Height

Max Platform Extension Length

Platform Load (Unrestricted)

Machine Gradeability (4WD)

Drive Speed (Stowed / Raised)

Turret Rotation

Platform Rotation

Platform Dimensions

Turning Radius (Inside / Outside)

Driving Steering Type

Power (Engine)

Machine Weight

30,000

22,900

300/454 Kg

45%

5 / 0.6 Km/h

360° (Con)

90°

 2,440 x 910 x 1,100

3,600 / 6,700

4WD x 2WS

Yuchai 55kW

18,900 Kg

3
2
4
5

Standard Features

Welcome to the future of aerial access solutions with the LiuGong’s LT28JG4 Telescopic Boom Lift. Designed to elevate your work to unprecedented heights while prioritizing safety, efficiency, and reliability, LiuGong’s state-of-the-art machine offers an array of features and benefits.

Double Redundancy Design: The LT28JG4 ensures precise control of each working range with its double redundancy design of limit switches and long-angle sensors. Safety is at the forefront of our design.
Platform Load Monitoring: Continuous monitoring of platform load with a high-precision weighing sensor guarantees the safety of your crew and equipment.
Virtual Wall Protection: Customizable virtual wall protection effectively safeguards the operator’s safety, preventing accidents and injuries.

Impressive Load Capacity: With an unrestricted load of 300kg and a 454kg restricted area load across the entire working range, the LT28JG4 can handle your most demanding tasks with ease.
Hydraulic Drive: A closed hydraulic drive system, combined with variable main pump and electric proportional control, ensures stable and efficient operation.
Automatic Balance Swing Bridge: The automatic balance swing bridge design adapts seamlessly to complex working conditions, allowing for smooth and precise movement.
Four-Wheel Drive: A fully hydraulic four-wheel drive system provides rapid response and superior maneuverability.
Multi-Functional Joystick: The multi-functional combined Hall full-scale effect joystick streamlines operation, enhancing efficiency and operator comfort.

Impressive Working Range: Enjoy a maximum working height of 30 meters, a maximum working outreach of 22.9 meters, and a wide working range that covers diverse job site needs.
Versatile Jib: The jib can rotate vertically at 135°, offering a working range from 60° downward to 75° upward.
Space-Saving Design: The four-bar linkage design results in a compact structure, making it easier to navigate tight spaces.

Real-Time Monitoring: Stay on top of maintenance with real-time monitoring and transmission of vehicle information, historical fault record queries, and helpful maintenance tips.
Working Condition Records: Keep comprehensive records of your equipment’s working conditions for better maintenance planning.
Self-Lubricating Bearing: Enjoy hassle-free maintenance with self-lubricating bearings and a screw-out engine tray.

The LT28JG4 comes equipped with a range of standard features, including platform working lights, a flashing amber beacon, anti-extrusion and over-tilt protective systems, a load sensing system, platform self-locking door, two-wheel steering, an auto brake system, all motion alarm, emergency descent and stop systems, automatic leveling, electro-hydraulic proportional control, a spacious three-entry large working platform, hydraulic oil dispersion, double work area, and a remote fault diagnosis system.
