Trailer Mounted Articulated Boom Lifts

Nifty Lift 01

Niftylift’s road towable trailer mounted cherry pickers can be transported easily from site to site and set up quickly using manual or hydraulic outriggers*. They are built to be as light and compact as possible and offer an excellent working envelope for their size, with working heights ranging from 9m (30ft) to over 21m (69ft).

Easy to use proportional controls make them simple to operate and features such as telescopic booms, fly-booms, platform rotation, traction drive and hydraulic outriggers* all help to maximize their effectiveness.

120

The Nifty 120 is a robust and versatile trailer mount. It has retractable axles that allow it to pass through a 1.1m wide opening or doorway giving better access to applications.

Operation is quick, easy and precise due to reliable fully proportional controls and its versatile battery power pack enables the Nifty 120 trailer mount to work inside and out quietly and with zero emissions.

The Nifty 120 trailer mount is a fast, cost effective and safe alternative to ladders and scaffolds.

Maximum Working Height

12.33 m

Maximum Working Outreach

5.00 m

Machine Dimensions

L 5.75 m, H 1.90 m, W 1.50m

Working Width

2.70 m Extended, 1.10 m Retracted

Cage Width and Depth

1.10 m, 0.65 m

Safe Working Load

200 kg

Outrigger Type

Manual

Maximum Slope

4% / 2.1°

Machine Weight

1195 kg

120T

The Nifty 120T trailer mount is specifically designed to give maximum reach performance from the most compact chassis possible. By utilizing  its versatile telescopic upper boom, the Nifty 120T trailer mount delivers unrivalled working outreach, especially at lower levels where it’s needed most.

Telescopic axles coupled with a very compact base make the Nifty 120T trailer mount one of the most compact and maneuverable trailer mounts available. The Nifty 120T trailer mount is also available with a traction drive option that offers a simple, cost effective and safe method for on-site positioning.

Maximum Working Height

12.20 m

Maximum Working Outreach

6.10 m

Machine Dimensions

L 4.50 m, H 1.90 m, W 1.50 m

Working Width

3.55 m Extended

Cage Width and Depth

1.10 m, 0.65m

Safe Working Load

200 kg

Outrigger Type

Hydraulic

Maximum Slope

11% / 6°

Machine Weight

1400 kg

150T

Developed specifically to maximize outreach, the Nifty 150T trailer mount delivers an unrivaled working envelope, especially at low levels where outreach is needed most. The Nifty 150T trailer mount offers an up-and-over clearance of more than 5.6m allowing it to reach easily over larger obstacles such as walls and buildings.

The Nifty 150T trailer mount is also available with a traction drive option that offers a simple, cost effective and safe method for on-site positioning

Maximum Working Height

14.70 m

Maximum Working Outreach

7.55 m

Machine Dimensions

L 5.55 m, H 2.00 m, W 1.60 m

Working Width

3.80 m Extended

Cage Width and Depth

1.40 m, 0.65 m

Safe Working Load

225 kg

Outrigger Type

Hydraulic

Maximum Slope

23% / 13°

Machine Weight

1775 kg

170

With one of the largest working envelopes in its class the Nifty 170 trailer mount delivers maximum reach with stability and control. Octagonal boom sections provide the Nifty 170 trailer mount strength without compromising on weight and the telescopic upper boom improves accuracy when positioning the platform. The Nifty 170 trailer mount’s outstanding reach makes it ideal for a wide range of applications.

The Nifty 170 trailer mount is also available with a traction drive option that offers a simple, cost effective and safe method for on-site positioning.

Maximum Working Height

17.10 m

Maximum Working Outreach

8.70 m

Machine Dimensions

L 6.20 m, H 2.15 m, W 1.65 m

Working Width

4.40 m Extended

Cage Width and Depth

1.10 m, 0.65 m

Safe Working Load

200 kg

Outrigger Type

Hydraulic

Maximum Slope

14% / 8°

Machine Weight

2160 kg

210

The Nifty 210 trailer mount has one of the largest unrestricted working envelopes in its class. The Nifty 210 trailer mount special boom design makes it ideal for working near walls or buildings. A single control allows its platform to move vertically while remaining parallel to the job, saving time and improving efficiency.

Platform rotation provides the Nifty 210 trailer mount greater maneuverability in the air and its fully proportional controls give the operator precise control when positioning the platform, even on hard to reach jobs.

Maximum Working Height

21.00 m

Maximum Working Outreach

12.00 m

Machine Dimensions

L 6.95 m, H 2.27 m, W 1.80 m

Working Width

4.30 m Extended

Cage Width and Depth

1.40 m, 0.70 m

Cage Rotation

100°

Safe Working Load

225 kg

Outrigger Type

Hydraulic

Maximum Slope

17% / 9.5°

Machine Weight

3495 kg
